DALI-H80

DALI PHANTOM H-80 SPECS

Product series PHANTOM
Frequency Range (+/-3 dB) [Hz] 46 - 25,000
Sensitivity (2,83 V/1 m) [dB] 90.0
Nominal Impedance [ohms] 6
Maximum SPL [dB] 109
Recommended Amplifier Power [W] 30 - 200
Crossover Frequency [Hz] 2,350
High frequency driver, Quantity 1 x 28 mm
High frequency driver, Diaphragm type Soft Textile Dome
Low frequency driver, Quantity 1 x 8"
Low frequency driver, Diaphragm type Wood Fibre Cone
Enclosure type Open back
Recommended Working Volume 15 - 100 L
Connection Input Single Wire
Recommended Placement In-Wall
In-Ceiling
Dimensions (HxWxD) [mm] 335 x 335 x 106
Cut-Out Dimensions (HxWxD) [mm] 299 x 299
Accessories Included 3mm Allen Key
Cut-Out Template
Logo Badge
Manual
Weight [kg] 3.30
Recommended Volume [litre] 15 - 100
