Cambridge DacMagic 200M – DAC Ultra HD con USB

D/A converters: Dual ESS ES9028Q2M DACs

Digital filter: Selectable, Fast – Slow – Short delay

Frequency response: 10Hz to 50KHz (±1dB)

THD+N @ 1kHz 0dBFs: <0.0005% (A-Weighted)

S/N ratio: >115dB (A-Weighted)

Crosstalk @ 10kHz: < -110dB

Output impedance: <50 Ohms (unbal), <100 Ohm (bal)

Max output level (unbalanced): 2.1V rms (fixed or variable – user selectable)

Max output level (balanced): 4.2V rms (fixed or variable – user selectable)

HEADPHONES

Headphone Output THD+N: < 0.001% at 1kHz 0dBFS @ 100mW into 32 Ohm

S/N: > 115dB (A-Weighted)

Max output power: >300mW @ 32 Ohm, >65mW @ 150 Ohm

Frequency response: 10Hz – 50KHz (±1dB)

Recommend Headphone impedance: 10 Ohm to 600 Ohm

Digital input word widths supported:
16bit (Bluetooth)
16-24bit (Optical, Coaxial)
16-32bit (USB)

Digital input sampling frequencies supported:
44.1kHz to 96kHz PCM, DoP64 (Optical)
44.1kHz to 192kHz PCM, DoP64 (Coaxial)
44.1kHz to 768kHz PCM, Native DSD 64x to 512x, DoP 64x to 256x (USB)

MQA compatibility: Full decoding (Core + Renderer)

Bluetooth: v4.2, A2DP profile, SBC and AptX codecs

Max power consumption: 12W

Color: Lunar Grey

Dimensions (H x W x D): 52 x 215 x 191mm

Weight: 1.2kg

Manuale DacMagic 200M: Download
